Heavy duty reel assembly
In order to improve feeding in any condition, the 9255 offers a completely redesigned larger more robust reel assembly. Our new reel gently moves tough tangled crops onto the draper belts for smooth efficient feeding without wrapping improving harvesting efficiency.
-
More
Improved end skid design
The angle and radius of the end skid has been optimized so that the skid can ride flatter on the ground, increasing the “footprint” of the skid. In addition to the improved skid design, larger hydraulic lines have been added to the 9255 to improve float suspension, leading to more constant ground pressure reducing end skid wear.
-
More
Single height skid design
The 9255 is equipped with a single height skid shoe design. Height is optimized to achieve the low cut height required in crops such as soybeans, while reducing the potential for crop to enter the bottom side of the draper belts.
-
More
-
-
More
Optimized cutter bar angle
Cutter bar tilt angle in the 9255 has been tilted back 5 degrees over previous models to maintain the optimal cutter bar to ground angle as the header is pitched forward. This improved cutter bar profile reduces cutter bar to ground contact as the header is pitched forward.
-
More
Long divider rods
The 9255 is equipped with a new long divider design which improves separation of the crop in densely tangled conditions, improves feeding onto the draper belts, reduces wrapping around the reel, and provides excellent visibility to the leading edge of the header.
-
More
Flywheel sickle drives
The 9255 is equipped with a mechanical driven flywheel sickle drive gearbox. The flywheel design allows the width of the end skid and header end panel to be decreased compared to previous models, approximately 3” on each end. This decrease in width reduces damage and loss in uncut standing crop as the header passes by putting more grain in your bin rather than on the ground.
-
More
- Europe, Middle East & Africa
-
Uk/Eire (English)
-
France (Français)
-
Deutschland (Deutsch)
-
Italia (Italiano)
-
Восточная Европа (Русский)
-
International (English)
- North America
-
USA & Canada (English)
- East Asia & Pacific
-
Australia and New Zealand (English)
Challenger 9255 DynaFlex
Flexible Draper Headers
NO CONDITION TOO TOUGH
The introduction of the Challenger 9255 Dynaflex header represents a significant step forward in flexible draper header performance. Building on the successes of the proven Challenger FDH line, the 9255 includes numerous new features to improve performance, reliability and productivity while retaining all of the features that built the proven Dynaflex name. In the end this header will deliver a successful harvest and add more to your bottom line.
Specifications
| Model | Cutting Width ft (m) | Cutter Bar | Cutter Bar Float in (mm) | Cutter Bar Drive |
|---|---|---|---|---|
| 9255-25 | 25 (7.6) | High Capacity or SCH | 8 (203.2) | Single Mechanical |
| 9255-30 | 30 (9.1) | High Capacity or SCH | 8 (203.2) | Dual Mechanical |
| 9255-35 | 35 (10.7) | High Capacity or SCH | 8 (203.2) | Dual Mechanical |
| 9255-40 | 40 (12.1) | High Capacity or SCH | 8 (203.2) | Dual Mechanical |
