More
20 Inch Auger
The large 20 inch diameter auger reaches over the gatherer and row unit for maximum capacity and efficient feeding in any condition.
-
More
Fore-Aft Header Tilt
Heads are equipped with hydraulic header fore-aft pitch capability, adjustable on the go from the cab. This allows the operator to “match” the header-feeding angle to the combine height for optimized feeding and exceptional downed corn performance. A hydraulic accumulator provides protection for the combine and header when running the header on the ground.
-
More
Optimized Stalk Rolls
Stalk rolls have point-to-point contact for improved feeding and greater performance. Additionally, the point-to-point design of the rolls ensures the stalk is pulled through without the side-to-side vibration associated with an interlocking roll design. This smoother operation leads to reduced header loss levels. Stalk rolls have point-to-point contact for better feeding and greater performance.
-
More
Chopping or Non-Chopping
Available in chopping or non-chopping models, the header allows you to operate in almost any field regardless of residue management preferences. The chopping heads allow the operator to engage or disengage chopping capabilities at each row unit with an easy to use lever.
-
More
-
-
More
Snout design
A cove shaped snout design gets under ears without knocking them loose and prevents the ramp launching of cobs. The snout shape is also optimized to slide under and gently pick up downed corn, allowing the header to perform well in a wide range of harvesting conditions.
-
More
Auger Flighting
Auger flighting pitch has increased while the auger speed has decreased. This allows the auger to gently convey more crop leading to reduced header loss while retaining maximum capacity.
-
More
Lugs and Gathering Chains
Design and length of lugs on gathering chains strip less leaves and reduce the amount of trash that is pulled into the machine, which means the combine processes less, increasing operating efficiency.
-
More
Center Auger Hood
The standard center auger hood prevents cobs from going over the top of the header opening while the canted shape of deck plate openings reduces impact shelling from cob impact.
-
More
Low Density Polyethylene Construction
The low-density polyethylene construction of our snouts and gatherers absorbs shock from ears reducing the number of bouncing ears and amount of butt shelling meaning the corn harvested makes it into the combine rather than getting left behind as header loss. Each snout is equipped with reflective markers to improve visibility to the snouts in low light situations.
-
More
-
-
More
Snout Skids
Take your harvest to the next level with these optional capabilities.
-
More
Reichhardt Row Guidance Ready Snouts
Command Series Corn head snouts are Reichhardt Row Guidance Ready and do not require modification to install row sensing.
-
More
Headsight Sensors
Equipping the Command Series corn head with Headsight sensors provides automatic header height control for more accurate and responsive height control. The increased height accuracy and responsiveness leads to reduced operator fatigue and maximized harvesting efficiency.
-
More
Stalk Crushers
The stalk stompers effectively crush the remaining standing stalk as the header passes over reducing tire hazards in the field.
-
More
- Europe, Middle East & Africa
-
Uk/Eire (English)
-
France (Français)
-
Deutschland (Deutsch)
-
Italia (Italiano)
-
Восточная Европа (Русский)
-
International (English)
- North America
-
USA & Canada (English)
- East Asia & Pacific
-
Australia and New Zealand (English)
Challenger 3300 Command Series
Corn Heads
TAKE COMMAND OF YOUR HARVEST
The Command™ series corn head is a totally new AGCO®-designed and built header that delivers increased capacity, faster harvesting rates and exceptional performance in downed corn with reduced header loss relative to both cobs and overall corn loss at the header itself. Take command of your harvest with the new 3300 Command series corn heads from Challenger®.
Specifications
| Model | Row Spacing | Chopping Capability | Recommended Combine Class | Auger Diameter | Auger Pitch |
|---|---|---|---|---|---|
| 3308 | 30" | No | 6, 7, 8 | 20" | 30" |
| 3308C | 30" | Yes | 6, 7, 8 | 20" | 30" |
| 3312 | 30" | No | 7, 8 | 20" | 30" |
| 3312C | 30" | Yes | 7, 8 | 20" | 30" |
Product Resources
Printed Literature
Order Your Full-Color Brochure
Discover more about the new Challenger product you'd like to own. By answering a few questions, you can sign up to receive an in-depth brochure by mail. You can also view our brochures online by clicking on a link to the right of this box or by visiting our Media Library.
Be sure to visit your local Challenger dealer, a great source for parts, literature and other product information.
Download Literature
